Using safe atmospheric rays for better, more portable and efficient detection of contraband items

The CosmoPort project will develop the next generation of scanner systems using Muon Transmission Tomography (MTT).

Project funded by European Commission
HORIZON-CL3-2022-BM-01-03
Research & Development

The development of the mobile scanner system will start from the core technology developed by GScan (TRL4). The primary focus point for the development to TRL7 will be spatial resolution improvements, mechanical stability and calibration algorithm development for the mobile purpose.

The most notable development points are:

• Develop and produce the geometrically customised and cost-optimised SiPMs.

• Develop and produce the cost-optimised Data Acquisition (DAQ) system.

• Develop and produce the mechanically more stable and higher-resolution position-sensitive Plastic Scintillator Fibre (PSF) based hodoscopes.

• Improve AI based reconstruction, tomography & material classification algorithms for mobile use.

• Develop mobile-system-specific (self)calibration algorithms.

Demonstrations

Following a dedicated methodology, the system will be deployed in five demonstration campaigns after having integrated all enhancements during laboratory testing. This offers the chance to the end users to bring forward valuable feedback which can be integrated to further evaluate the system and set the basis for the technical partners to further fine-tune the system’s components accordingly in the future.

The CosmoPort demo methodology is aiming at:

• Initiating constructive and trustful relationships with end-users taking into account that their availability will be limited and the that the CosmoPort team will build its works on a “synthetic information” basis.

• Developing high TRL demonstrators for improved capacities of the proposed solution and enhanced interoperability and high availability requirements.

• Producing appropriate reports on the operational impact that the five realistic scenarios will demonstrate.

Out-performing X-ray technologies

•  Muon transmission tomography, or ART-systems, offers a unique blend of 3D imaging with atomic composition data, a capability that traditional X-rays lack.

• They utilize autonomous decision-making through machine learning, reducing the need for human interpretation, and are cloud-ready for seamless integration with the IoT.

• ART-based technologies are highly scalable, allowing for versatile applications limited only by creativity.

• With no artificial radiation source, these systems are radiation-free and easily modifiable, enabling novel uses such as mobile solutions.

• They also significantly reduce operating costs due to extended lifespan, reduced power consumption, and absence of radiation-related regulations or equipment needs.

• Safe to operate.

Milestones

To achieve the main objectives, i.e. the development of a AI-based MRT scanner for significantly improving the detection capacity of threats and illicit goods in trade flows, CosmoPort engages together internationally recognized researchers and developers from different research domains: (i) ART scanners, (ii) AI-learning and risk assessment, (iii) police and customs. As such disciplines and high-level competence rarely exist under the same roof, it is of utmost important to gather the expertise of partners into one consortium working towards achieving the prominent goals.
Q4 2023

Project kick-off

2024

The requirements for a mobile scanner have been identified and the testing methodology described.

The research and development work necessary for the production of the mobile scanner has been carried out.

2025

Mobile scanner system is commissioned and tested.

2026

Mobile scanner system demonstrated in operational environment

Airport passenger security and random cargo checks

Brand identity
UI&UX
Graphic design
Web development

Random security checks at airports have become increasingly essential in the face of evolving threats to aviation safety. Muon transmission tomography, with its capacity to provide highly detailed images of luggage and cargo, offers a crucial tool for enhancing airport security. By conducting non-intrusive scans of checked and carry-on baggage, this technology enables authorities to detect hidden items of concern, such as explosives or weapons, while minimizing the inconvenience to passengers. It not only improves security but also helps maintain the smooth operation of airports, reducing delays and enhancing overall passenger experience.

View website

Logistic centres of smaller courier companies

Brand identity
UI&UX
Graphic design
Web development

Muon transmission tomography holds great potential in optimizing security measures within logistic centers of smaller courier companies. This advanced imaging technology offers a non-invasive solution for screening packages and cargo, allowing for the detection of concealed contraband, hazardous materials, or threats without the need for physical inspection. By implementing muon tomography, smaller courier companies can enhance their security protocols, streamline cargo screening processes, and significantly reduce the risk of potential security breaches. This technology not only bolsters security but also ensures the efficient flow of goods, contributing to the overall success of these courier companies.

View website

Small-scale maritime cargo checks

Brand identity
UI&UX
Graphic design
Web development

The security of yacht harbors is a priority, given the potential for maritime environments to be exploited for illicit activities. Muon transmission tomography can play a pivotal role in ensuring the safety and security of these harbors. By conducting non-invasive scans of vessels, this technology can identify potential security risks, such as hidden contraband or concealed weapons, promoting a safer maritime environment. By implementing such advanced imaging systems, authorities can effectively deter illegal activities and ensure the protection of both yacht owners and the surrounding community.

View website

Optimization of the usage of stationary x-ray system

Brand identity
UI&UX
Graphic design
Web development

Certain concealed materials, including those wrapped in dense substances like lead, foil, and plastic, remain undetectable by conventional X-ray scanning systems. This limitation underscores the need for more advanced imaging technologies, such as muon transmission tomography, which could potentially surpass X-ray measurements. Muon transmission tomography offers the advantage of providing highly detailed 3D images of objects, rendering it a promising solution for security and inspection purposes. The technology's ability to penetrate dense materials could significantly enhance detection capabilities, making it a valuable asset in security operations where traditional X-ray systems fall short.

Customs X-ray machines can’t track shabu (methamphetamine) wrapped in lead, foil, plastic

Let's answer some FAQ's

Don’t hesitate to reach out if you have any questions
What are muons? How does muon tomography (muography) work?
Are muons hazardous?
How long does MTT measurement take in comparison to X-ray ?
Are muon transmission tomography imaging results as good as X-ray?
What can muon tomography detect?

Let us know if you want to talk about CosmoPort!
